Description

GP03 unsaturated polyester glass mat sheet is a rigid insulation board made through hot pressing of glass fiber mat, impregnated with unsaturated polyester resin, with corresponding additives. Temperature resistance of the polyester glass laminate is up to class B.

Available Model: GPO-3 (UPGM 203 in IEC standard)

Features
1. The composite sheet boasts superb electrical insulation performance, mechanical performance, and material uniformity in all orientations.
2. With excellent machinability, the polyester glass mat sheet can be machined to various parts through turning, milling, punching, drilling, sand blasting, grinding and other processes.
3. It is suitable for fitting all kinds of metal inserts, with high ease of use and practicality.

Specifications
Standards: GB/T 1303.7-2009, IEC, NEMA, MIL-I-24768
Colors: White, red, grey or as customer request
Certificates: UL, Reach, RoHS
Size (W x L): 980 x 1980mm, 1010 x 2020mm,1250 x 2500mm
Thickness: 0.8-65mm

Applications
1. The polyester glass mat laminate sheet is ideal for making insulation board and lining board, arc extinguishing chamber, cylinder and plate, flash barrier, wiring board, contact plate and other parts for all kinds of switch cabinets.
2. It can also be used to make structural support, busbar clamp plate and busway insulation material for switches and transformers, and to make armature parts, cover plate, slot wedge stator and gasket, backplate and shim for motors.
3. In addition, the glass mat sheet is an ideal insulation material for electric furnace, locomotive and other industries.
